Cereal bar making machine HTL-608

HTL-608 Fully Automatic Cereal, Energy, and Nut Bar Production Line

Description

The HTL-608 is a fully automated production line engineered for high-efficiency manufacturing of cereal bars, energy bars, nut bars, peanut candy bars, sesame candy bars, and other cut-and-shaped confections. This system integrates advanced food processing technology with a user-friendly interface to deliver precision cutting, consistent forming, and high-volume output with minimal labor involvement.

Key Features

1. Integrated Mixing and Cutting System

• Combines three core processes—mixing, forming, and cutting—into one continuous line, eliminating manual intervention and significantly reducing labor costs.

1. Manual Cutting Simulation with Frequency Control

• Replicates the precision of manual cutting using frequency conversion speed control, allowing for customization across a variety of product textures and shapes.

1. Multi-Level Flattening System

• Ensures even product thickness with uniform pressing, along with automatic feeding, horizontal and vertical cutting, and box size customization.

1. Smart Control via PLC System

• Features a PLC intelligent control panel for fast operation setup, parameter adjustments, and ease of use.

1. High-Speed Cutting Efficiency

• Equipped with a continuous rotary cutter capable of producing up to 2000 pieces per minute, dramatically boosting productivity.

1. Adjustable Cutting Dimensions

• The cross-cutting mechanism allows free adjustment of length and angle without interruption.

1. Uniform Material Distribution

• Uses an unequal-distance auger for consistent and uniform material layering across the entire width.

1. Smooth Surface Finishing and Adjustable Thickness

• Designed for clean, bright surface finishing, and easy control over product thickness.

1. Durable Stainless Steel Construction

• Built with food-grade stainless steel for long-term durability, easy cleaning, and compliance with hygiene standards.

Main Technical Specifications

The HTL-608 Automatic Bar Production Line is engineered for high-performance processing with precision and scalability. It features a 400 mm effective working width, capable of producing a wide range of bar sizes. The system supports customizable product lengths ranging from 0–100 mm and 100–200 mm, providing flexibility for various formulations and packaging formats.

Powered by a 6 kW system, the machine operates at 380V / 50Hz, suitable for standard industrial power supplies. Built entirely from food-grade stainless steel, the equipment ensures hygienic operation, durability, and ease of cleaning.

• The overall structure measures 9800 × 1000 × 1300 mm and weighs approximately 2000 kg, making it a stable and robust addition to any production line. With its high-speed cutting capabilities and intelligent control system, the HTL-608 delivers consistent output and exceptional efficiency for commercial-scale bar production.
