Heat Shrink Packaging Machine HTL_590/180

HTL-590/180 Heat Shrink Wrapping Machine

Main Performance & Features

The HTL-590/180 is a high-performance heat shrink wrapping system designed for reliable, hygienic, and efficient packaging across a wide range of industries. It is ideal for both industrial-scale operations and small to medium-volume packaging lines.

This system consists of three main components:

• Main Shrink Wrapping Unit
• Input Conveyor
• Output Conveyor

Key features include:

• Heavy-Duty Construction:
• The main machine body is welded from 12mm-thick steel plate, specially heat-treated for long-lasting durability and vibration resistance.
• Food-Grade Hygiene:
• All product-contact surfaces are made from SU304 stainless steel, compliant with food safety standards. External covers are crafted from baked enamel-coated steel plates for enhanced corrosion resistance.
• Efficient Heat Sealing System:
• The middle sealing unit is directly heated, providing faster heat-up times, longer element lifespan, and reduced energy consumption—ideal for high-throughput environments.
• Versatile Use Across Projects:
• The HTL-590/180 is compatible with a variety of heat-shrink films (PVC, OPP, POF, etc.) and supports a wide range of packaging sizes. It is suitable for wrapping food products, consumer goods, and more, making it a go-to machine for both high and low-volume packaging operations.

Scope of Application

• Food products
• Industrial goods
• Consumer retail packaging
• Multi-pack bundling and tamper-proof wrapping

Technical Specifications

ParameterSpecificationModelHTL-590/180Maximum Packaging Material Width590 mmPackage DimensionsLength: 90–400 mmWidth: 30–200 mmHeight: 40–120 mmPacking Speed50–150 packages per minuteMachine Dimensions (L × W × H)5000 × 1105 × 1750 mmNet Weight1200 kgCompatible Packaging MaterialsPVC, OPP, POF, etc.Power Supply220V / 50HzPower Consumption3.66 kW
