Automatic Cutting And Packaging Machine HTL-S808

HTL-S808 Candy Cutting & Wrapping Machine

Product Description

The HTL-S808 is a high-efficiency candy packaging machine developed and manufactured using advanced West German technology. It features a precision-engineered linear channel for feeding, integrated cutting, and wrapping—controlled by a state-of-the-art PLC (Programmable Logic Controller) system. Its gear transmission mechanism is powered by an adjustable three-phase asynchronous motor, allowing flexible and smooth operation.

The machine includes a seven-station intermittent-motion wrapping plate that ensures a consistent flow of candy during packaging. An automatic spray lubrication system supports long-term stable operation while reducing maintenance requirements. All components in contact with the product are made from non-toxic, food-grade materials, ensuring safety and hygiene in production.

Thanks to its reliable performance, modern control system, and user-friendly maintenance design, the HTL-S808 is a preferred solution in the confectionery packaging industry.

Application Scope

The HTL-S808 is suitable for the automatic cutting, forming, and wrapping of various types of confectionery products. It supports both:

• Fold wrapping
• Double twist wrapping

Ideal for packaging:

• Milk candy
• Hard candy
• Bubble gum

Main Technical Parameters

ParameterSpecificationModelHTL-S808Wrapping Speed150–500 bags per minuteVoltage380V / 50HzTotal Power Consumption3 kWNoise LevelLess than 70 dBStandard ColorLorry-whiteDimensions (L × W × H)1440 × 1185 × 1810 mmWeight1300 kgCompatible Wrapping MaterialsExternal paper, glassine, aluminum foil, internal paper
