Tablet Candy Forming Machine

High-Performance Tablet Press Machine

Product Description

This Tablet Press Machine is designed for the high-speed, high-pressure compression of powder into tablets—suitable for applications in the pharmaceutical, food supplement, confectionery, and chemical industries. With reliable mechanical performance and adjustable settings, this machine can produce a wide range of tablet sizes and shapes with precision and consistency.

Built for efficiency, the press is equipped with 17 die stations and is capable of delivering continuous, high-volume tablet output while maintaining uniform density and thickness. Its compact design and robust construction ensure stability and long-term performance under industrial conditions.

Technical Specifications (Narrative Form)

The machine features 17 dies, enabling high-output rotary compression. It provides a maximum tablet pressure of 40 kN, which ensures solid compression for tablets up to 16 mm in diameter, with a maximum filling depth of 15 mm and a maximum tablet thickness of 6 mm.

The turntable speed is adjustable between 20 and 40 revolutions per minute, giving it a production capacity ranging from 20,400 to 45,600 tablets per hour, depending on setup and product type.

It is driven by a 2.2 kW motor operating at 960 RPM, and requires a 380V / 50Hz power supply, standard for industrial equipment.

The machine has a compact footprint with overall dimensions of 880 × 750 × 1600 mm, and a net host weight of 560 kg, making it suitable for both standalone use and integration into automated production lines.

This tablet press is an excellent solution for manufacturers seeking high output, adjustable tablet parameters, and operational stability in a wide variety of compression applications.
