Multifunction candy depositing line HTL-T150/T300/T450/T600

HTL-T150/T300/T450/T600 Multifunction Candy Depositing Line

Product Description

The HTL-T series Multifunction Candy Depositing Line is a fully automatic hard candy and lollipop production system independently developed by Haitel. It is designed to meet the modern demands of mass production with high efficiency, consistent quality, and versatility in shape, color, and flavor.

The line integrates advanced features such as continuous pouring, automatic demoulding, and fan-forced cooling, making it a comprehensive solution for industrial candy manufacturing. By changing molds or depositing heads, the system can flexibly produce multi-colored, multi-flavored, or filled candies in various shapes—including traditional hard candies and lollipops.

Key Features

1. Advanced Process Control
2. Equipped with a PLC or computer-based control system and LED touchscreen interface for intuitive operation and real-time process management.
3. Flexible Production Capacities
4. Available in models with output capacities of 150, 300, 450, and 600 kg/h, supporting both small and large-scale manufacturing.
5. Hygienic & Durable Construction
6. All food-contact components are made of SUS304 stainless steel, meeting strict hygiene and durability standards.
7. Precise Dosing and Mixing
8. Includes:

• Frequency-controlled mass flow system
• In-line injection and pre-mixing for liquids (e.g., color, flavor, acids)
• Optional jam-center filling system for filled candies

1. Stable Cooking Process
2. Features an automatic steam control system to maintain consistent steam pressure, ensuring stable candy quality over long production runs.
3. Custom Mold Options
4. Molds and depositing heads can be customized based on customer-supplied candy samples.

Application Scope

The HTL-T series is suitable for the pouring and shaping of hard candies and lollipops in various:

• Shapes (round, oval, custom designs)
• Colors and layers (striped, filled, multi-colored)
• Centers (optional fruit jam or soft fillings)

Production Process Flow

Sugar Melting → Sugar Storage → Sugar Cooking → Depositing & Molding → Cooling → Demoulding → Packaging

Technical Specifications

The HTL-T series candy depositing line is available in four capacity models to meet varying production needs:

• The HTL-T150 model offers a production capacity of 150 kg per hour. It requires 8 kW of power and consumes 0.20 m³/min of compressed air. The overall dimensions of the machine are 8500 × 1100 × 1800 mm, and its total weight is approximately 3000 kg.
• The HTL-T300 model is designed for medium-scale operations with a capacity of 300 kg per hour. It operates at 12 kW and requires 0.25 m³/min of compressed air. The machine measures 10,000 × 1600 × 1800 mm and weighs around 3500 kg.
• For higher output demands, the HTL-T450 delivers up to 450 kg per hour, powered by a 16 kW system and consuming 0.40 m³/min of compressed air. Its dimensions are 10,000 × 2200 × 1800 mm, with a total weight of 4200 kg.
• The largest model, HTL-T600, supports a maximum capacity of 600 kg per hour. It consumes 20 kW of power and requires 0.45 m³/min of compressed air. The machine size is 10,000 × 2600 × 1800 mm, with a total weight of approximately 5000 kg.
