Bag Type Automatic Packaging Machine HTL-G6 (G8)

HTL-G6/G8 Automatic Bag Feeding Packaging Machine

Main Performance and Structural Features

The HTL-G6/G8 is a high-performance automatic bag-feeding packaging machine, independently developed to meet the needs of intelligent, high-speed, and multi-material packaging. It is equipped with advanced automation technology to perform a full range of packaging functions without manual intervention.

Key Features:

• Fully Automated Bag Handling: The system includes a robotic manipulator and supporting mechanisms that automatically pick up pre-made bags from the bag magazine, open them, print the production date and batch number, fill the product, and seal the bag—entirely autonomously.
• Modular Integration for Vacuum Packaging: The machine can be paired with a vacuum system to form a complete unit for automatic vacuum bag feeding, vacuum extraction, and product discharge—enabling fully unmanned vacuum packaging.
• Flexible Material Feeding Options: Depending on your production needs, the system can integrate various feeding mechanisms such as:
• Liquid or paste metering systems
• Multi-head weighing scales
• Powder feeders
• Granule feeders
• Block product feeders
• Or a combination of these for mixed-material packaging
• Advanced Control and Monitoring: Controlled via PLC and operated through an intuitive human-machine interface (HMI), the system features real-time operational monitoring. In the event of abnormalities, the system triggers an alarm output to prevent material and packaging waste and allow timely intervention.
• Versatile Application: Designed for packaging a wide variety of materials including powder, liquids, pastes, granules, and solid blocks, using premade bags.

Scope of Application

This machine is ideal for industries such as:

• Food and Beverage (e.g. sauces, powders, snacks)
• Pharmaceuticals
• Chemicals
• Household Goods

Its adaptability makes it suitable for vacuum-packed products, ready-to-eat foods, granular commodities, liquids, and more.

Technical Specifications

• Model: HTL-G6 / HTL-G8
• Machine Dimensions: 1650 × 1550 × 1600 mm
• Applicable Bag Size: Width: 100–200 mm; Length: 130–350 mm
• Supported Packaging Materials: Solid blocks, powders, liquids, pastes
• Packing Speed: 40–60 bags per minute (depending on material and configuration)
• Power Supply: 380V / 50Hz
• Compressed Air Requirement: 5–8 kgf/cm²
• Machine Weight: 1500 kg
