Chocolate Automatic Sorting Folding Packing Machine HTL-1000-Z360

Technical Specifications – Model HTL-1000-Z360

The HTL-1000-Z360 is a high-efficiency envelope-fold packaging machine, designed specifically for wrapping products of unique or irregular shapes and sizes. Ideal for items such as chocolates, waffles, and coated foods, it supports both single and double aluminum film wrapping, ensuring excellent product protection and presentation.

Scope of Application

This machine is suitable for envelope-style packaging of:

• Chocolate products
• Waffles
• Coated snacks and confections
• Other specialty items requiring neat fold wrapping

Supports single-layer or dual-layer aluminum film wrapping for improved shelf life and aesthetics.

Machine Specifications

• Model: HTL-1000-Z360
• Product Size Range:
• Length: 30–95 mm
• Width: 20–50 mm
• Height: 6–10 mm
• Film Width: 55–150 mm
• Wrapping Speed: 150–300 bags/min
• Power Supply: 380V / 50Hz / 3-phase
• Total Power: 3.5 kW
• Machine Dimensions: 2600 × 1400 × 1150 mm
• Weight: 1800 kg
