Chocolate Automatic Sorting Twist Packing Machine HTL-1000-S360

Double Twist Chocolate Packaging Machine – Model HTL-1000-S360

Main Features & Performance

The HTL-1000-S360 is a fully automatic double twist packaging machine designed for high-speed and precision wrapping of chocolate products. With full servo control and intelligent automation, it ensures consistent packaging quality and smooth operation in demanding production environments.

Key Features

1. Full Servo Intelligent Control
2. Delivers smooth, quiet operation with high stability, improving overall workplace comfort and machine reliability.
3. Fully Automated Workflow
4. Integrates material handling, feeding, wrapping, and twisting in a single streamlined process. Directly connects to the production line for uninterrupted automation.
5. Intuitive Menu-Based Operation
6. Easy-to-use interface with real-time parameter display for simplified control and setup.
7. Specialized Structure Design
8. Tailored for chocolate products, enabling seamless integration and high-speed double twist wrapping for uniform, attractive packaging.

Application Scope

Ideal for automatic double twist packaging of:

• Cylindrical chocolates
• Square chocolates
• Rectangular chocolate bars

This machine is especially suited for confectionery production lines requiring consistent presentation and high-speed output.

Production Flow

Pouring line → Sorting & conveying → Product alignment → Double twist wrapping

Technical Specifications – Model HTL-1000-S360

The HTL-1000-S360 is a fully automatic double twist packaging machine, engineered for high-speed, precision wrapping of chocolate products. It features full servo control, intelligent automation, and a specialized design tailored for cylindrical, square, and rectangular chocolates.

Machine Specifications

• Model: HTL-1000-S360
• Maximum Production Capacity: Up to 360 bags per minute
• Packaging Dimensions:
• Length: 20–80 mm
• Width: 10–25 mm
• Height: 10–25 mm
• Packaging Film:
• Maximum Diameter: Φ300 mm
• Maximum Width: 125 mm
• Total Installed Power: 12 kW
• Power Supply: 380V, 50Hz, 3-phase
• Total Weight: 1500 kg
• Machine Dimensions: 6000 mm (L) × 1750 mm (W) × 1800 mm (H)
