High-Speed Automatic Sorting Pillow Packing Line HTL-A1200-1

Key Features – Intelligent Pillow Packaging Machine

• Full Servo Control: Instant bag length adjustment with smart cutter splitting via input setting.
• Fully Automated Process: From feeding to sealing, the system integrates seamlessly into production lines with minimal manual intervention.
• Smart Material Detection: Ensures no empty packages — the cutter pauses automatically if material is missing, avoiding film waste.
• Precision Control: High-speed microprocessor with dynamic sealing curves and ±0.1 mm color mark tracking for accurate, stable performance.
• User-Friendly Interface: Intuitive LCD touch screen for simplified operation and real-time monitoring.
• Low Noise & Durable: Quiet operation with automatic belt correction, reducing wear and extending service life.
• Non-Stop Film Splicing: Built-in automatic film-connecting system for continuous packaging and reduced downtime.

Application Scope

Ideal for automatic pillow packaging of solid items such as chocolates, grain bars, square or round snacks, and other small food products.

The HTL-A1200-1 is a high-speed, fully automatic packaging machine designed to deliver efficient, precise, and continuous packing for small-sized products. Engineered for reliability and performance, this model is ideal for use in food, pharmaceutical, and consumer goods industries where high throughput and compact packaging are essential.

Main Features and Performance

• Maximum Production Capacity: Capable of delivering between 200 to 900 bags per minute, the HTL-A1200-1 ensures fast and stable packaging for high-volume operations.
• Packaging Range: Accommodates products with dimensions of
• Length: 55–72 mm
• Width: 15–35 mm
• Height: 5–20 mm
• Film Specifications:
• Maximum Film Diameter: Φ300 mm
• Maximum Film Width: 150 mm
• Power Requirements:
• Total Installed Power: 7.5 kW
• Power Supply: 380V / 50Hz (3-phase)
• Machine Dimensions: 6000 mm (L) × 1200 mm (W) × 1700 mm (H)
• Total Weight: 1300 kg
