S50 AND RECORD 10HS

S50 – AUTOMATIC SEALING SIDE

EXTERNAL DIMENSIONS OF THE MACHINE

LENGTH: 2,250 mm

WIDTH: 950 mm

Height: 1,500 mm

Exit roller: Not included

WORKING LEVEL : 900 mm + / – 50 mm

Net Weight: 600 Kg

TECHNICAL INFORMATION

Product width: from 10 mm to 400 mm

Product length: from 10 mm to infinitive

Product height: from 10 mm to 200 mm

Product weight: from 70 gr. to 25 kg.

Conveyor Speed : 3 – 30 m / minute

Power supply: 208 V (60 Hz) 3 PH + N + Ground

Consumption: 5 KW

Pneumatic supply: 8.6 bars

Bar temperature: 180°C – 200°C

SEALED

Motorized adjustment of film sealing and height group to seal the film at a perfect level relative to the product height

MACHINE CAPABLE OF HANDLING

POLYPROPYLENE – LDPET – PVC – POLYOLEFIN

10HS record – shrink-wrap tunnel

EXTERNAL DIMENSIONS OF THE TUNNEL

Machine size 3620 x 1310 x 2020 mmh

Chamber size 1900 x 600 x 400 mmh

DESCRIPTION

Wire mesh conveyor belt, driven by a gear motor

Tunnel L 1,900mm

(Insulated with mineral wool – heated by armoured resistors)

Tunnel mouth passage opening (600 mm W x 400 mm H)

Forced ventilation and air recycling system

Adjustable temperature via digital thermostat

Pre-switching OFF

(When the tunnel cools below 80 degrees the machine stops automatically)

9 resistors x 4000 watts

External adjustment of the air circulating inside the tunnel chamber

Electronic control panel incorporated into the machine body

Installed power 37 KW.

Spare parts kit for the first intervention

OPTION

Cooling Unit after Shrink Tunnel
